Multimode Laser Diode Arrays
Multimode laser diode arrays and bars from 660 nm to 1850 nm with 10 W to 5600 W output, for pumping, heating, hair removal and materials processing.
30 products · page 1 of 2
| Model | Wavelength | Power | Operating Temp. | Package | Datasheet |
|---|---|---|---|---|---|
| BAR-105 | 1470 nm | 20 W | -40 to 60°C | Bar | |
| BAR-107 | 1470 nm | 28 W | -40 to 60°C | Bar | |
| BAR-114 | 1560 nm | 27.5 W | -40 to 60°C | Bar | |
| BAR-165 | 1310 nm | 30 W | -40 to 60°C | Bar | |
| FDL-1470-20W | 1470 nm | 20 W | 20 to 30°C | * | |
| FFL-808-250W-HCSQ | 808 nm | 250 W | 15 to 35°C | CS-Mount | |
| FFL-808-60W-HCS | 808 nm | 60 W | 15 to 35°C | CS-Mount | |
| FFL-940-80W-HCS | 940 nm | 80 W | 15 to 35°C | CS-Mount | |
| FFL-976-80W-HCS | 976 nm | 80 W | 15 to 35°C | CS-Mount | |
| FFL-980-80W-HCS | 980 nm | 80 W | 15 to 35°C | CS-Mount | |
| FLC-PML150 | 1450 nm | 25 W | CS-Mount | ||
| FLC-PML170 | 1470 nm | 25 W | CS-Mount | ||
| FLC-PML185 | 1850 nm | 10 W | CS-Mount | ||
| FLX-1064-40W-100×24 | 1064 nm | 40 W | 20°C | CS-Mount | |
| FLX-1064-40W-150×19 | 1064 nm | 40 W | 20°C | CS-Mount | |
| FLX-660-10W-100×19 | 660 nm | 10 W | 15°C | CS-Mount | |
| FLX-670-10W-100×19 | 670 nm | 10 W | 15°C | CS-Mount | |
| FLX-680-12W-150×19 | 680 nm | 12 W | 15°C | CS-Mount | |
| FLX-690-12W-150×19 | 690 nm | 12 W | 15°C | CS-Mount | |
| FLX-730-20W-150×19 | 730 nm | 20 W | 20°C | CS-Mount | |
| FLX-750-20W-100×24 | 750 nm | 20 W | 20°C | CS-Mount | |
| FLX-760-20W-150×19 | 760 nm | 20 W | 20°C | CS-Mount | |
| FLX-795-30W-150×19 | 795 nm | 30 W | 20°C | CS-Mount | |
| FRLD-796-3600W-Stack | 796 nm | 3.600,000W | 0 to 60°C | ||
| FRLD-796-5600W-Stack | 796 nm | 5.600,000W | 0 to 60°C |
